single turn potentiometer
WTH118 2W100K ohm Single Turn Carbon Film Welding Machine Regulating Potentiometer
product name WTH118-2W 100K ohm Dual Gang Potentiometer Carbon Linear Variable Turn Rotary Potentiometer product description WTH118 single turn carbon film potentiometer, rated power: 2W, shape: circular, revolution: 1 turn, shaft: metal shaft, resistance material: carbon film, resistance adjustment method: rotary, resistance change method: X type (linear), allowable deviation of resistance value: 10 (%) Product Features Single coil carbon film potentiometer WTH118
P16 P16NP Single Turn Knob Potentiometer WI1609 Cermet 1W 10% Trimmer Potentiometer
P16 P16NP Single Turn Knob Potentiometer with Switch Sealed potentiometer WI1609 cermet 1W 10% trimmer potentiometer product name: P16 P16NP Single Turn Knob Potentiometer with Switch Sealed potentiometer WI1609 cermet 1W 10% trimmer potentiometer product description: The P16 is a revolutionary concept in panel mountedpotentiometers. This unique design consists of a knobdriving and incorporating a cermet potentiometer. Only themounting hardware and terminals are situated on
WX112 WX050 5W Single Turn Wire Wound Potentiometer Adjustable Resistance 100R 330R 470R
WX112 WX050 5W single turn wire wound potentiometer adjustable resistance 100R 330R 470R 1K 2K2 3K3 4K7 product name: WX112 WX050 5W single turn wire wound potentiometer adjustable resistance 100R 330R 470R 1K 2K2 3K3 4K7 5K6 6K8 10K 22k 33K 47K product description: WX112 single-coil wire winding potentiometer shaft diameter: 6mm, shaft rod specification: 20-ZS-3, outer diameter: 45mm, resistance accuracy: 5% 10%, power: 5W, packing: 20pcs/box Product Features: WX112 WX050
WX118 Carbon Film Wirewound Potentiometer Single Turn 1K 2K 5K
WX118 Long Handle 50mm Wirewound Potentiometer 1K 2K 5K 10K 5% product name: WX118 Single turn carbon film rotary wirewound potentiometer 1K 2K 5K 10K 5% Long handle 50mm Short handle 20mm product description: Electrical characteristics Range of nominal resistance: 25~25K Resistance Tolerance: 5% Terminal resistance:0.2%R or 5 Peak Noise:100 Insulation resistance: 200M (100V AC) Withstand voltage:500V (DC or AC peak value) Electrical angle:258 5 Environmental
WX112(050) 2.2K 5% 5W Variable Resistor single turn Wirewound Potentiometer
product name: WX112 WX050 5W single turn wire wound potentiometer adjustable resistance 100R 330R 470R 1K 2K2 3K3 4K7 5K6 6K8 10K 22k 33K 47K product description: WX112 single-coil wire winding potentiometer shaft diameter: 6mm, shaft rod specification: 20-ZS-3, outer diameter: 45mm, resistance accuracy: 5% 10%, power: 5W, packing: 20pcs/box Product Features: WX112 WX050 Single -wire Winding Power Titles Features: Linear stability, uniform rotation damping, uniform
RVQ24YN03 20S 25F B502 5K 102 202 103 302 Simulator Single-Turn Carbon Film Potentiometer Racing Game Machine
RVQ24YN03 rotary potentiometer 10k with ip67 waterproof Products datasheet: 1.) Mechanical specifications: a.) total rotational angle: 30010 b.) rotational torque: 20~200gf.cm c.) click position is available d.) rotation stop strength: 8kgf.cm Max e.) residual resistance: Max 10 ohm 2.) Electrical specifications: a.) total resistance range: 500 ohm = 1M ohm 30% b.) resistance taper: A, B, C, D c.) power rating: 0.2 w d.) Max. operating voltage: AC 500 V e.) rotational
3386P Single Turn Trimming Potentiometer 0.5w 10% 1K 2K 5K 10K 20K 50K 100K 3386 Variable Resistor
product name: 3386 series single turn metal glass glaze preset Potentiometer product description: The 3386 Potentiometer is one of the glass glazed precision single loop adjustable Potentiometer. The color of the product is generally blue, and occasionally it is specially customized. 3386 Potentiometer are divided into Potentiometer with handles and Potentiometer without handles. The handles are 8mm, 3mm and 5mm long. The 3386 Potentiometer is widely used in communication
Single Circle WX14-12 3W Wirewound Potentiometer 1K 2K2 3K3 4K7 20K 10K 22K 100R 470R
WX14-12 3W single turn Wirewound Potentiometer 1K 2K2 3K3 4K7 20K 10K 22K 100R 470R product name: WX14-12 3W single turn Wirewound Potentiometer 1K 2K2 3K3 4K7 20K 10K 22K 100R 470R product description: WX14-12 single-circle wire winding power unit, power of 3W, axis diameter 4mm, outer circular diameter 24mm, open hole 8.3mm, accuracy: 5% knob angle: 300 C, axis length: 20mm, resistance: 27 33 47 56 56 56 68 100 220 270 330 470 560 680 1K 1K5 2K3 4K7 5K1
W206 0.25W Single Coil Potentiometer with Easy Adjustment and Long-Term Workability
product name: W206 0.25W Single Coil Potentiometer with Easy Adjustment and Long-Term Workability W206 single coil metal glass glaze preset potentiometer 0.25W product description: The W206 single coil metal glass glaze pre adjustable potentiometer is suitable for electronic devices such as audio amplifiers, mixing consoles, and recorders. Its rated power is 0.25W, and the W206 single turn glass glaze fine adjustment potentiometer adopts a single turn design, made of metal
