Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset

Product Details

Place of Origin: Sichuan, China

Brand Name: BONENS

Model Number: Metal pushbutton switches

Payment & Shipping Terms

Packaging Details: Carton packaging

Delivery Time: 5-8days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Get Best Price

Product Details

Product Description
Highlight:

Black Metal Push Button Switch

,

Latching Push Button Switch

,

Waterproof Push Button Switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset
Product Description
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 0
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 1
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 2
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 3
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 4
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 5
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 6
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 7
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 8
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 9

Self-locking button

Press the button to power on, and press the button again to power off
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 10

Self-reset button

Press the button to power on, release the button to power off
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 11

Ring light button switch

Button: Flat button Lights: Ring lights Button Material: Stainless Steel
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 12

Power light button switch

Button: Flat button Lights: Power icon lights Button Material: Stainless Steel
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 13

Lightless pushbutton switch

Buttons: Flat buttons Lighting: No light Button Material: Stainless Steel

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 14

Convex pushbutton switch

Button: Convex button Button light: Power icon light Button Material: Stainless Steel
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 15

Pushbutton switch with wire

Button: Flat button Button light: with light/without light Button Material: Stainless Steel Cable: With plug and play cable
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 16

Button socket connector

Copper core PVC monobloc outer skin Solder-free, plug and play The default line length is 15cm

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 17



Red LED light power icon button switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 18



Yellow LED light power icon button switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 19



Blue LED light power icon button switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 20



Green LED light power icon button switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 21



White LED light power icon button switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 22




Ring red LED light pushbutton switch
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 23



Ring Yellow LED light pushbutton switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 24



Ring Blue LED light pushbutton switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 25



Ring White LED light pushbutton switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 26



Ring Green LED light pushbutton switch

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 27



Flat button switch without light

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 28



Metal pushbutton switch with conductive electricity

Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 29
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 30
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 31
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 32
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 33
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 34
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 35
Specification
Product Name:
Metal pushbutton switches
Type of operation:
Self-reset/self-locking switch
Rated current:
3A 5A
Wiring:
Welding feet
Contact Form:
12mm:1NC 16mm/19mm/22mm:1NO1NC
Cut-out size:
12mm,16mm,19mm,22mm,25mm,30mm
Housing Material:
Made of metal
Operating Voltage:
3V-220V
Ingress Protection:
12mm/16mm/19mm:IP66 22mm:IP67
Light Color:
Red/Yellow/Blue/Green/White
Mechanical life
Self-resetting: 1,000,000 times Self-locking: 500,000 times
Product Specifications
AC 220V
AC 110V
DC 24V
DC 12V
DC 6V
12mm

Current rating
0.5A
1A
1A
2A
2A
16~30mm
4A
5A
2A
4A
4A
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 36
Waterproof Doorbell 12/16/19/22mm Latching Black Metal Push Button Switch with Customizable Logo and Self-Reset 37
